15 Inch Tilt Touchpanel Crestron Isys™ TPS-6000
3. Select the Add button to transfer the WAV file to the Sound List table
located below the browse field. The audio parameters of the file also
appear to the right of the table.
4. Repeat steps 1 through 3 for each desired WAV file.
NOTE: To remove a WAV file from the Sound List table, highlight the file and
click on the Remove button.
The Properties button opens the “Sound Properties” window for a highlighted WAV
file in the Sound List table. The designer can assign a join number either
automatically with the Auto button or by scrolling down to the desired number.
Select Description to enter comments about the WAV file.
Reserved Join Numbers
A reserved join number is a feature of the software that enables a designer to create a
button that completes a predetermined function. The tables on the next few pages
provide lists of reserved join numbers available within the software.
NOTE: Many touchpanel configuration “shortcuts” are available via the software.
A button can be created on a page that either calls up the Preferences Menu, adjusts
brightness, etc., via reserved join numbers.
NOTE: Reserved join numbers can also be automatically activated by a control
system when using join number remapping. Refer to the latest version of the Join
Number Remapping Reference Guide (Doc. 5969) and the SIMPL Windows help
file for more details.
System Analog Reserved Join Numbers for TPS-6000 Touchpanels
JOIN # FUNCTION VALUE IN/OUT
17200 Cresnet ID Setting Cresnet ID INPUT/OUTPUT
17201 Brightness LCD Brightness INPUT/OUTPUT
17202 Power Down Timeout Power Down INPUT/OUTPUT
17203 System Standby Time Out INPUT/OUTPUT
System Digital Reserved Join Numbers for TPS-6000 Touchpanels
JOIN # FUNCTION VALUE IN/OUT
17200 System Off N/A INPUT
17214 Cresnet ID Down INPUT/OUTPUT
17215 Cresnet ID Up INPUT/OUTPUT
17216 Brightness Increase INPUT
17217 Brightness Decrease INPUT
17218 Brightness High INPUT
17219 Brightness Medium INPUT
17220 Brightness Low INPUT
17231 Standby Timeout Up INPUT
17232 Standby Timeout Down INPUT
continued on next page
32 • 15 Inch Tilt Touchpanel: Crestron Isys™ TPS-6000 Operations Guide - DOC. 5864A
