Crestron Isys™ TPS-6000 15 Inch Tilt Touchpanel
Specifications
The following provides a summary of specifications for the TPS-6000 touchpanel.
Specifications for the TPS-6000 Touchpanel
SPECIFICATION DETAILS
Power Requirements
(without cards)
1
24 Watts (1 Amp @ 24 VDC)
Default Network ID 03
Timeout
Adjustable from 0 to 120 minutes (Default = 15
min.)
Signal Join Maximums 4000 Digital and Analog, 999 Serial
Control System Update
Files
2,3,4
2-Series Control System Version C2-2004.CUZ or later
3
CEN/CN-TVAV Version 51130V.UPZ or later
4,5
CNMSX-AV/PRO Version 51125X.UPZ or later
4,5
CNRACKX/-DP Version 51125W.UPZ or later
4,5
CNMS, CNRACK,
CNLCOMP
Version 3.18.09m, l, c or later
4,6
ST-CP Version 4.00.49S.UPZ or later
6
Audio
• Balanced (20 kΩ) & unbalanced (10 kΩ)
line level stereo input through 6-pin mini-
connector.
• Maximum input level 2 Vrms single ended
(unbalanced), 4 Vrms differential
(balanced) with internal volume control
and two speakers.
• Balanced (2.0 Vrms) and unbalanced
(1.0 Vrms) line level microphone output
with AGC output (3x sensitivity) via 3-pin
mini connector.
• Maximum output level 1 Vrms single
ended, 2 Vrms differential
• Built-in WAV file (8 & 16 bit PCM mono &
stereo, 8 kHz, 11 kHz, 16 kHz, 22 kHz, &
44 kHz) playback capability
7
• Speaker amplification: 2 Watts per
channel
Touchpanel Firmware TPS.V.2.000.0.csf or later
Memory
8MB internal flash memory (upgradeable to 16 MB
or 32MB), 8MB of DRAM
8
Screen Dimensions 15"/38.1 cm diagonal
Screen Viewing Angles: Y Dir. (X=0
o
): +60
o
(from top), -60
o
(from bottom)
X Dir. (Y=0
o
): +70
o
(from right), -70
o
(from left)
Screen Resolution 1024 x 768 pixels
Color
16 Bit non-palette graphics with color key video
window capability, 65,536 colors
(continued on next page)
Operations Guide - DOC. 5864A 15 Inch Tilt Touchpanel: Crestron Isys™ TPS-6000 • 3
