Crestron Isys™ TPS-6000 15 Inch Tilt Touchpanel
System Digital Reserved Join Numbers for TPS-6000 Touchpanels (continued)
JOIN # FUNCTION VALUE IN/OUT
17233 Power Down Timeout Up INPUT
17234 Power Down Timeout Down INPUT
17242 Call up Setup Menu N/A INPUT
17265
through
17280
1
Touchout Action
Touchout Action
(Device A)
INPUT/OUTPUT
17281
Input next Touchout
action
Up (Dev. A) INPUT
17282
Input next Touchout
action
Down (Dev. A) INPUT
17818
through
17833
2
Touchout Action
Touchout Action
(Dev. B)
INPUT/OUTPUT
17834
Input next Touchout
action
Up (Dev. B) INPUT
17835
Input next Touchout
action
Down (Dev. B) INPUT
1. Join numbers 17265 through 17280 corresponds to Touchout action 0 through Touchout Action F on
Device A sequentially.
2. Join numbers 17818 through 17833 corresponds to Touchout action 0 through Touchout Action F on
Device B sequentially.
System Serial Reserved Join Numbers for TPS-6000 Touchpanels
JOIN # FUNCTION VALUE IN/OUT
32768 Product Name “TPS-6000” OUTPUT
32769 Product Version
Firmware
Version”
OUTPUT
Audio Analog Reserved Join Numbers for TPS-6000 Touchpanels
JOIN # FUNCTION VALUE IN/OUT
17300 Key Click Volume INPUT/OUTPUT
17301 Audio Line Volume INPUT/OUTPUT
17302 WAV Audio Volume INPUT/OUTPUT
17303 Audio Line Balance INPUT/OUTPUT
17304 WAV Audio Balance INPUT/OUTPUT
Audio Digital Reserved Join Numbers for TPS-6000 Touchpanels
JOIN # FUNCTION VALUE IN/OUT
17300 Audio On INPUT/OUTPUT
17301 Audio Off INPUT/OUTPUT
17302 Key Click On INPUT/OUTPUT
17303 Key Click Off INPUT/OUTPUT
17304 Key Click Volume Increase INPUT
17305 Key Click Volume Decrease INPUT
17306 Audio Line On INPUT/OUTPUT
continued on next page
Operations Guide - DOC. 5864A 15 Inch Tilt Touchpanel: Crestron Isys™ TPS-6000 • 33
