Audio Digital Reserved Join Numbers for TPS-6000 Touchpanels (continued)
JOIN # FUNCTION VALUE IN/OUT
17307 Audio Line Off INPUT/OUTPUT
17308 Audio Line Volume Increase INPUT
17309 Audio Line Volume Decrease INPUT
17310 Audio Line Balance Left INPUT
17311 Audio Line Balance Right INPUT
17312 Audio WAV On INPUT/OUTPUT
17313 Audio WAV Off INPUT/OUTPUT
17314 Audio WAV Volume Increase INPUT
17315 Audio WAV Volume Decrease INPUT
17316 Audio WAV Balance Left INPUT
17317 Audio WAV Balance Right INPUT
17318 Audio Mic AGC On INPUT/OUTPUT
17319 Audio Mic AGC Off INPUT/OUTPUT
17321 Audio Defaults* INPUT
17322 Key Click Duration Short INPUT
17323 Key Click Duration Medium INPUT
17324 Key Click Duration Long INPUT
* Audio Defaults: Master 88%, Wav 88%, Line 88%, Key Click 29%, All Audio On, Mic AGC On.
Video Analog Reserved Join Numbers for the TPS-6000 Touchpanels
JOIN # FUNCTION VALUE IN/OUT
17100 Video 1
1,2
Brightness INPUT/OUTPUT
17101 Video 1
1,2
Contrast INPUT/OUTPUT
17102 Video 1
1,2
Saturation INPUT/OUTPUT
17103 Video 1
1,2
Hue INPUT/OUTPUT
17150 Video 2
2
Brightness INPUT/OUTPUT
17151 Video 2
2
Contrast INPUT/OUTPUT
17152 Video 2
2
Saturation INPUT/OUTPUT
17153 Video 2
2
Hue INPUT/OUTPUT
1. Available when TPS-VID-1 is installed.
2. Available when TPS-VID-2 is installed.
Video Digital Reserved Join Numbers for TPS-6000 Touchpanels
JOIN # FUNCTION VALUE IN/OUT
17101 Video 1
1, 2
Video Composite TP INPUT/OUTPUT
17102 Video 1
1, 2
S-Video TP INPUT/OUTPUT
17103 Video 1
1, 2
Auto Detect TP INPUT/OUTPUT
17104 Video 1
1, 2
Video Composite BNC INPUT/OUTPUT
17105 Video 1
1, 2
S-Video BNC INPUT/OUTPUT
17106 Video 1
1, 2
Auto Detect BNC INPUT/OUTPUT
17107 Video 1
1, 2
Still INPUT/OUTPUT
continued on next page
34 • 15 Inch Tilt Touchpanel: Crestron Isys™ TPS-6000 Operations Guide - DOC. 5864A
