8.4” WiFi Touch Screen Crestron TPMC-8X-GA
Connectors, Controls & Indicators
# CONNECTORS,
CONTROLS &
INDICATORS
DESCRIPTION
1 Stylus
Used to “tap” or to do “select and drag” functions
just as you would using a mouse;
Also used to “type” on the input screen
“keyboard” when entering text or commands
2 Power LED
(1) Green LED, indicates touch screen power
status
3 Battery LED
(1) Green/yellow dual color LED, indicates
battery condition and charging status;
When AC is offline and the external battery is
connected, the touch screen will use the external
battery before using the internal battery and the
LED will remain solid green; Once the internal
battery is in use, the LED will remain solid green
if battery level is above 25% (±3%) of full charge,
solid yellow if charge drops to 25% (±3%) and
blinking yellow if battery level drops to 10%
(±3%); When AC is online and battery is
charging, the LED will be blinking green until
charge is 100%, at which time it will light solid
green
4 Wi-Fi LED
(1) Green LED, indicates wireless network
connection status:
Solid green – communicating with a wireless
access point (WAP)
Blinking green – searching for a WAP
Off – no wireless communication (unit is in power
down mode or power is off)
5 Power Button
(1) Push button, initiates “Power On” and Power
Down”:
Press to turn touch screen power on; Press again
to put touch screen in power down mode; Press
to restore full on mode; Press and hold for four
seconds to turn power off (The recommended
method for shutting down the touch screen is to
press the Shut Down button on the setup menu.)
6
Thumbpad &
Arrows
1
(1) programmable 5-way thumbpad (4-way
navigation plus center “Enter” button) and (2)
programmable up/down push buttons
7
Headphones
(1) 3.5 mm TRS mini phone jack;
Stereo headphone output
8 Memory Card
(1) MMC compatible card slot
2
inside battery
compartment;
Accepts up to 4 GB MMC (not included)
9 Battery Switch
(1) Recessed slide switch inside battery
compartment, shuts off battery for long term
storage; refer to “Internal Battery Switch” on page
12
(Continued on following page)
10 • Isys
®
8.4” WiFi Touch Screen: TPMC-8X-GA Operations Guide – DOC. 7078C
