Crestron TS-1070 User Manual

Product Manual — Doc. 8555F TS-70 Series • 1
Overview
The Crestron® TS-770 and TS-1070 are tabletop touch screens that feature web browsing,
Smart Graphics® software and HTML5 UItechnology, custom-programmable virtual buttons,
H.265/H.264 streaming video, a Rava®SIPintercom , Wi-Fi® network connectivity , and PoE+
(Power over Ethernet Plus)network power. The touch screens also provide built-in applications
for room scheduling, conferencing, and home control.
NOTE:The TS-770 and TS-1070 are functionally similar. For simplicity within this
documentation, the term "touch screen"is used except where otherwise noted.
Crestron offers the following variations for its standard touch screen models. Certain settings
described in this document are not applicable to these models.
l
The TS-770-GV and TS-1070-GVseries touch screens eliminate the microphone, the
Bluetooth® communications beacon, and Wi-Fi network connectivity to comply with
government applications demanding extra privacy and security.
l
The TS-770R and TS-1070Rseries touch screens are designed specifically to run the
Crestron Home™ OShome control application.
Features
Refer to the following sections for more information on the features provided by various TS-70
Series models.
l
TS-770 Features (on page2)
l
TS-770-GV Features (on page8)
l
TS-770R Features (on page13)
l
TS-1070 Features (on page16)
l
TS-1070-GV Features (on page22)
l
TS-1070R Features (on page27)

Crestron TS-1070 Specifications

General

Resolution	1280 x 800 pixels
Touch Technology	Projective capacitive
Power over Ethernet	Yes
Wi-Fi	Yes
Camera	No
Microphone	Dual, front-facing
Ethernet	10/100/1000 Mbps
Bluetooth	No
Speakers	Yes
Operating System	Android™ 9
Processor	Quad-core
Memory	2 GB RAM
Storage	16 GB Flash
Connectivity	Ethernet, Wi-Fi
Display Size	10.1 inches
Mounting	Wall or Tabletop
Power Supply	PoE
