R&R Wheel Bearing
Removal of Wheel Bearing:
1. Place the trike on the center stand on a suitable
lift.
2. Remove the five lug nuts and the wheel assembly.
3. Remove the two 3/8 – 24 x 1 HHCS and the brake
caliper.
4. Remove the brake rotor.
5. Remove the half shaft nut from the wheel bearing.
6. Remove safety clip from bottom of upright.
7. Tap roll pin threw upright.
8. While pulling downward on the half shaft rotate the
upright upwards and remove the half shaft from
the wheel bearing.
9. Support the upright in the upward position.
10. Remove the three 1/2 – 20 x 2 HHCS, three 1/2 –
20 nyloc nuts, and three 1/2 special washers.
11. Remove the wheel bearing assembly.
Installation of the new wheel bearing assembly:
1. Install the new wheel bearing into the upright.
2. Reinstall the three 1/2 –20 x 2 HHCS and special
washers from the inside of the upright into the
wheel bearing.
3. Reinstall the three 1/2 – 20 nyloc nuts and torque
to specification. Use thread locking agent.
Warning: Ensure that the flats on the nut do not engage
the outside diameter of the wheel bearing.
4. Lubricate the splines on the half shaft with suitable
multi-purpose grease.
