INSTALLATION
Page 3-1
PREPARATION FOR USE
1. Inspect all equipment for damage that may have occurred during
shipment. Contact Cincinnati Sub-Zero immediately if any
shipping damage is noticed.
2. Ensure that all packing materials have been removed from all
parts.
3. Read this manual in its entirety.
4. Select a suitable location for chamber.
a. A minimum clearance of 12” (31 cm) must be
maintained for proper ventilation around the sides of the
chamber. The rear of the chamber must have at least 30”
(70 cm) of clearance for ventilation. If the unit has the optional
up -blast enclosure, no additional clearance is required
behind the unit. Water and electrical connections
should be fl exible and be at least 3 ft (92 cm) long so the unit
can be services easily.
b. The chamber must be installed in an environment of
75ºF ±10ºF (+23ºC±6ºC) with a maximum relative
humidity of 95% for proper operation and a maximum
elevation of 5000 ft (609.6m).
c. Units give off between 6,000 (1.76 kw) and 50,000
BTU/HR (14.65 kw) of heat to the room, depending
on the unit. There must be a means of removing this
heat to keep the chamber environment within spec.
d. Select a suitable location for the Chamber. The
location must be smooth and level with a maximum
slope in any direction of 1/8” (3 mm)x 10’ (3 m).
e. Unit lifting points are designated with fork lift labels.
f. Forks should extend passed the other side of the
chamber to prevent damage.
g. When transporting the chamber is should be 2”-3” off
the fl oor.
h. The rear of the chamber is heavier than the front due
to the location of the refrigeration compressors.
5. To Level Unit:
a. Leveling feet have been provided at the front of the
unit. A 1/2” (13 mm) open end wrench can be used
to extend the leveling feet. The unit must be level
or slightly tilted to the rear for proper water drainage in
the chamber.
b. If the door is binding, the hinge side leveling foot must
be extended approximately 1/4” (13 mm) higher than
the latch side leveling foot.
NOTE
Results may not be immediate,
please wait several hours before
continuing adjustments.
Do not locate system in a area
near fl ammable or toxic material.
Failure to follow these instructions
may result in serious personal
injury.
WARNING
!
In moving or relocating the chamber,
never tip the unit more than 45
degrees without instructions from
Cincinnati Sub-Zero.
CAUTION
!
Maximum water inlet pressure is
10 PSI (170 kPa) for an atomizer
and 25 PS (274 kPa)I for a boiler.
Exceeding this pressure may
cause catastrophic failure of the
fi lter housing. For optimal use of
the atomizer and boiler systems,
inlet water pressure should not fall
below 10 PSI (69 kPa) for both
boilers and atomizers.
WARNING
!
Only qualified maintenance
personnel should be permitted
to perform any maintenance or
installation procedures.
WARNING
!
