CTC Union IMC-1000C - Device Anatomy and Configuration; Panel Component Identification

8
Panels
No.
Description
1
Power terminal block
2
Earth ground connector
3
LED indicators
4
LAN interface
5
Function DIP switch
6
Fiber interface (Fixed fiber or SFP slot)
7
Earth ground sign
Figure 1. Front Panel
of IMC-1000C
8
Figure 3. Top Panel
2
4
3
6
6
5
1
6
2
1
7
2
Figure 2. Front Panel
of IMC-1000CS
