CTC Union IMC-1000C User Manual

9
Fiber & LAN Connection
Both Fiber and LAN interface are located on the front panel. The
Fiber interface of IMC-1000C(-E) supports 1000Mbps and has fixed
optical transceiver options for connector types of ST or SC; whereas, the
fiber interface of IMC-1000CS(-E) utilizes a SFP slot that supports
100/1000Mbps. The LAN connection of both IMC-1000C(-E) & IMC-
1000CS(-E) supports 10/100/1000Base-T and uses a shielded RJ-45
connector which supports Auto MDI/MDI-X.
Configuration settings are accomplished via a 4-pole DIP switch.
Please see below for the settings of the operation mode switch.
DIP Switch Function Descriptions
Pole No.
Status
Setting
Function Description
1
OFF *
Switch
Switching mode.
ON
Pass Thru
Pass through converter mode.
2
OFF *
Disable
Disable link fault pass through.
ON
LFP
Enable link fault pass through.
3
OFF *
FX Auto
Fiber duplex auto mode.
ON
Force
Fiber force mode.
4
For IMC-
1000CS(-E)
Only
OFF *
1000
Force Fiber speed to 1000Mbps.
ON
100
Force Fiber speed to 100Mbps.
NOTE 1: By default, all DIP switches are set to OFF (marked with *).
NOTE 2: When LFP is enabled, the LAN port (Fiber port) link down will force Fiber
port (LAN port) link down.
