CTI 2572-B / 2500C-2572-B Installation and Operation Manual 93
WX2 and WY4 Relationships
The following illustrates the relationship between the first four bits in WX2 and WY4. This relationship applies
to the other three sets of bits.
Word
Bit 1
Bit 2
Bit 3
Bit 4
WX2
CMD Err
PLC Err
CMD Busy
Abort Busy
WY4
ERR Ack
CMD Mode
CMD Trigger
Abort Trigger
Error Processing Bits
The module will set CMD ERR any time an error occurs in processing a command. The module will also set PLC
ERR if a valid Command Block cannot be read from V memory. After setting the error bits, the module will halt
processing on this command. The PLC acknowledges the error by setting ERR
ACK. When the module sees ERR
ACK go high, it aborts the command, clears the error bits, and is ready to accept another command trigger for
this slot.
Command Processing Bits
The PLC sets the CMD MODE bit to select whether Coupled Mode or Uncoupled Mode is used. The PLC sets
the CMD TRIGGER to initiate the command. When the module begins command processing, it sets the CMD
BUSY bit. The CMD BUSY bit will remain on until the module has completed processing the command.
Abort Processing Bits
The PLC can set the ABORT TRIGGER to request the module to abort a command that is in process. When the
module starts the process of aborting a command, it raises the ABORT BUSY bit. When the process is complete,
it lowers ABORT BUSY (and also CMD BUSY).
The timing diagrams in this appendix describe the interaction of the various Command Control and Command
Status bits.
