SERVICE - 1 - 4
Metal Power Switch Repair :
Please refer to SERVICE-1 Steering Cover Repair steps as
follows:
※Find the metal power switch connector (figure on the right)
※Reconnect the metal power switch connector
※If it is not effective, go to “Metal Power Switch Replacement”
below.
Metal Power Switch Replacement :
Please refer to SERVICE-1 Steering Cover Repair steps as follows:
1.Use needle-nosed pliers to unfasten the nut
2.Remove the metal power switch nut
3.Take out the switch, and replace it with a new one
※After the replacement of parts or re-installation, please follow the exact reverse sequence
for reassembly.
※If switch function has not been restored, refer to SERVICE-1-1 Top Control Panel
Repair.
•The metal power switch can be fastened in place by hand. An overly tight
fastening can cause the touch panel to be dented inwards.
•Do not put any force on the metal power switch circuit to prevent any
damage that might affect its function.
