SERVICE - 13 - 6
Sliding Base Repair :
Carry out all the SERVICE-13 Frame Repair SERVICE-13-1 Solenoid Valve Repair
SERVICE-13-2 Sliding Track Repair, steps and then :
1.Remove the two screws in the middle of the frame.
2.Take out the U-shaped saddle.
3.Remove the screws under the linear actuator (gas spring for the manual version).
4.Use an Allen driver (#6) to hold the hex screws, and turn the quick-release nut by hand
for removal.
5.Take out the sliding base.
6.At this stage the rear frame is completely removable and could be replaced during this
operation.
※When replacing the unit, follow the exact sequence of steps in reverse.
※For linear actuator repair, please refer to SERVICE-13-7 Linear Actuator Repair.
※For repair of the gas spring, please refer to SERVICE-13-8 gas spring Repair.
