Ctouch Canvas User Manual

2
Share, inspire, have fun!
With CTOUCH by your side.
CONTENT
Content ....................................................................................................................................................................2
Important information ...................................................................................................................................3
Important safety precautions ....................................................................................................................4
Standard accessories ......................................................................................................................................8
Vesa mount installation .................................................................................................................................9
Control panel .....................................................................................................................................................10
Connection panel ............................................................................................................................................. 11
Connections ....................................................................................................................................................... 12
Remote control ................................................................................................................................................14
Basic operations .............................................................................................................................................. 15
Setting menu .....................................................................................................................................................18
Troubleshooting ............................................................................................................................................... 21
Specifications ................................................................................................................................................... 22

Ctouch Canvas Specifications

General

Panel type	TFT
Color depth	8 bit
Pixel pitch	0.42975 x 0.42975 mm
Screen shape	Flat
Response time	8 ms
Backlight type	Direct LED
Display diagonal	74.54 \
Surface hardness	Mhos 7
Touch technology	Multi-touch
Display brightness	350 cd/m²
Display glass type	Tempered glass
Display technology	LCD
Native aspect ratio	16:9
Maximum refresh rate	60 Hz
Contrast ratio (typical)	4000:1
Display number of colors	1.073 billion colors
Display diagonal (metric)	189.3 cm
Number of simultaneous touchpoints	20
Certification	WEEE
Product color	Black, Grey
Glass thickness	4 mm
Cables included	AC, HDMI, USB, USB Type-C
Audio input	Mini Jack
USB hub version	3.2 Gen 2 (3.1 Gen 2)
DisplayPort version	1.2
HDMI ports quantity	3
USB upstream port type	USB Type-C
USB Type-A downstream ports quantity	5
AC input voltage	100 - 240 V
Power supply type	AC
AC input frequency	50 / 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	120 W
Panel mounting interface	800 x 600 mm
On Screen Display (OSD) languages	DEU, DUT, ENG
Package depth	225 mm
Package width	1873 mm
Package height	1186 mm
Package weight	72600 g
Placement supported	Horizontal
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	2
Built-in camera	No
RMS rated power	80 W
Sustainability certificates	CE, RoHS

Weight and Dimensions

Depth (without stand)	104 mm
Width (without stand)	1727 mm
Height (without stand)	1020 mm
Weight (without stand)	61700 g
