Ctouch Canvas User Manual

CTOUCH Canvas
23
ctouch.eu
SPECIFICATIONS
CONNECTION TERMINALS OF THE CTOUCH INTERACTIVE DISPLAY
HDMI In 3
DP (Display Port) In 1
USB-C (USB 3.1 Gen 2) 1
HDMI Out 1
VGA (incl. Mini Jack) 1
Audio In (Mini Jack) 1
SPDIF 1
USB 3.0 3
USB 2.0 2
Touch Out 3
RS232C 1
LAN 2
OPS slot 1
CTOUCH module slot 1
Notes:
1. Design and specifications are subject to change without notice.
2. Weight and dimensions shown are approximate.
3. Specifications and external appearance may be changed for the sake of
improvement.
* Due to different standby conditions, the standby power consumption of some models
could be higher than 0.5W.
Changes or modifications void any warranty and exclude any liability. This user manual includes detailed instructions for your product. Figures
and illustrations in this user manual are provided for reference only and may differ from actual equipment appearance. Equipment design and
specifications may be changed without notice.
CTOUCH Europe BV - Achtseweg zuid 153 R, 5651 GW Eindhoven, The Netherlands

Ctouch Canvas Specifications

General

Panel type	TFT
Color depth	8 bit
Pixel pitch	0.42975 x 0.42975 mm
Screen shape	Flat
Response time	8 ms
Backlight type	Direct LED
Display diagonal	74.54 \
Surface hardness	Mhos 7
Touch technology	Multi-touch
Display brightness	350 cd/m²
Display glass type	Tempered glass
Display technology	LCD
Native aspect ratio	16:9
Maximum refresh rate	60 Hz
Contrast ratio (typical)	4000:1
Display number of colors	1.073 billion colors
Display diagonal (metric)	189.3 cm
Number of simultaneous touchpoints	20
Certification	WEEE
Product color	Black, Grey
Glass thickness	4 mm
Cables included	AC, HDMI, USB, USB Type-C
Audio input	Mini Jack
USB hub version	3.2 Gen 2 (3.1 Gen 2)
DisplayPort version	1.2
HDMI ports quantity	3
USB upstream port type	USB Type-C
USB Type-A downstream ports quantity	5
AC input voltage	100 - 240 V
Power supply type	AC
AC input frequency	50 / 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	120 W
Panel mounting interface	800 x 600 mm
On Screen Display (OSD) languages	DEU, DUT, ENG
Package depth	225 mm
Package width	1873 mm
Package height	1186 mm
Package weight	72600 g
Placement supported	Horizontal
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	2
Built-in camera	No
RMS rated power	80 W
Sustainability certificates	CE, RoHS

Weight and Dimensions

Depth (without stand)	104 mm
Width (without stand)	1727 mm
Height (without stand)	1020 mm
Weight (without stand)	61700 g
