Ctronics CTIPC-260CWS User Manual

www.ctronicssecuritycameras.com
7
00000000
0 11110000
15 01111000 30 10110100 45
10000000
1 00001000
16 11111000 31 01110100 46
01000000
2 10001000
17 00000100 32 11110100 47
11000000
3 01001000
18 10000100 33 00001100 48
00100000
4 11001000
19 01000100 34 10001100 49
10100000
5 00101000
20 11000100 35 01001100 50
01100000
6 10101000
21 00100100 36 11001100 51
11100000
7 01101000
22 10100100 37 00101100 52
00010000
8 11101000
23 01100100 38 10101100 53
10010000
9 00011000
24 11100100 39 01101100 54
01010000
10 10011000
25 00010100 40 11101100 55
11010000
11 01011000
26 10010100 41 00011100 56
00110000
12 11011000
27 01010100 42 10011100 57
10110000
13 00111000
28 11010100 43 01011100 58
01110000
14 10111000
29 00110100 44 11011100 59
２、Baud rate setting (The baud rate is adaptive , this part is only the setting of
reference on the previous products)
Baud rate can set through the 4th ~5th dial codes，Can be set up the baud rate to
2400BPS、4800BPS、9600BPS、19200BPS。dial every number to be "ON" is means
as 1, dial to be "OFF" is means as 0，Baud rate and dial codes switch matching sheet
reference sheet 3 .
sheet3
：
Baud rate and dial codes switch matching sheet
Dial codes
2400 bps 4800 bps 9600 bps 19200 bps
No.4
OFF ON OFF ON
No.5
OFF OFF ON ON
３、Protocol setting
