Cub Cadet 2146 Parts Manual

-9-
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 611-3008 Axle Assy, LH, 11.9" Lg 1
2 716-3015 Ring, Inverted Retainer 2
3 721-3020A Seal, Oil 2
4 741-3033A Bearing 2
5 716-3018 Ring, External Retaining 2
6 619-3025 Housing, LH Axle 1
7 710-1008 Screw, Hex L-Wash Tap, 3/8-16 x 1.88 16
8 727-3085 Dipstick, OIl 1
9 715-3045 Bushing, Dowel 4
10 619-3037B Housing, LH Differential 1
11 710-0606 Screw, Hex Cap, 1/4-20 x 1.5 2
12 736-0463 Washer, Flat, .25 x .62 x .052 4
13 710-0788 Screw, Hex Wash Hd Tap, 1/4-20 x 1.0 15
14 710-1346 Screw, Plug, M14 x 1.5 x .827 1
15 715-3045 Bushing, Dowel 2
16 741-0361 Bearing, Ball 3
17 750-3133 Spacer, .757 ID x 1.0 OD x 1.46 1
18 717-3388 Gear, 27T Drive 1
19 717-3374 Shaft, Drive 1
20 717-3347 Gear, 36T Bevel 1
21 717-3391 Gear, 16T Spur 1
22 750-3134 Spacer, .885 ID x 1.125 OD x 1.4 1
23 717-3387 Gear, 18T Shift 1
24 718-3039 Collar, Drive 1
25 732-3113 Spring, Compression, 1.015 ID x 1.6 1
26 711-3379A Shaft, Shifter 1
27 741-3057 Bearing, Ball, .787 x 1.85 x .551 3
28 717-3392 Gear, 42T Spur 1
29 717-3346 Shaft, 9T Output 1
30 741-3037 Bearing, Ball 2
31 710-0151 Screw, Hex Cap, 3/8-24 x 2.0 4
32 619-3013 Cover,Differential 2
33 736-0423 Washer, Flat, 1.0 x 1.56 x .010 Thk AR
34 736-0431 Washer, Flat, 1.0 x 1.56 x .015 Thk AR
35 736-0424 Washer, Flat, 1.0 x 1.56 x .020 Thk AR
36 736-0420 Washer, Flat, 1.0 x 1.56 x .040 Thk AR
37 717-1159 Gear, 60T Bull 1
38 717-1119 Gear, 14T Differential Side 2
39 717-1190 Block, Differential Thrust 4
40 717-1120 Gear, 10T Differential Pinion 4
41 717-1178 Shaft, Cross 2
42 717-1173 Shaft, Cross, .50 OD x 3.485 Lg 1
43 712-3054 Nut, Hex Lock, 3/8-24 4
44 721-3008 O-Ring, 3/8 ID x 1/2 OD 1
45 618-3084 Yoke Assy, Shift (Incl. Ref #44) 1
46 619-3036A Housing, RH Differential 1
47 712-0291 Nut, Hex Center Lock, 1/4-20 2
48 721-3029 Seal, Shift Shaft 1
49 761-3019 Drum, Brake 1
50 732-3077 Spring, Brake 1
51 761-3020 Shoe, Brake 2
52 732-0152 Spring, Compression 1
53 703-2191 Arm, Brake 1
54 618-3060 Plate, Brake 1
55 761-3028 Actuator, Brake Shoe 1
56 710-3262 Screw, Low Hd Cap, 3/8-16 x .75 1
57 611-3009 Axle Assy, RH, 15.6 Lg 1
58 619-3024 Housing, Axle, RH 1
59 717-1180 Block, Differential Pinion 1
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
HYDRO TRANSMISSION

Cub Cadet 2146 Specifications

General

Transmission Type	Hydrostatic
Drive	2WD
Front Tires	16 x 6.5-8
Engine Type	4-cycle OHV
Fuel Capacity	11.4 l
Wheelbase	119 cm
Weight	229 kg
