Cub Cadet 2146 Parts Manual

-12-
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 603-0160 Arm Assembly, Control 1
2 703-2440 Bracket, Hydro Neutral 1
3 703-2441 Arm, Neutral 2
4 710-0106 Screw, Hex Cap, 1/4-20 x 1.25 1
5 710-0788 Screw, Hex Wash TT-Tap, 1/4-20 x 1 2
6 710-3242 Screw w/Patch, Set 1
7 712-0324 Nut, Hex Top Lock, 1/4-20 1
8 716-0111 Ring, Snap, .875 Shaft 1
9 723-3014 Filter, Oil 1
10 727-3002 Connector, Tube 37 Deg. w/O-Ring 1
721-3001 O-Ring, 3/8 OD Tube 1
11 727-3086 Elbow, Adjustable w/O-Ring 1
721-3002 O-Ring, 1/4 OD Tube 1
12 727-3088 Tube, Pickup 1
13 732-3119 Spring, Extension, .5 OD x 1.97 Lg 1
14 736-0176 Washer, Flat, .25 x .93 x .120 Thk 2
15 737-3022 Nipple, Oil Filter 1
16 750-0918 Spacer, Centering 1
NEUTRAL LINKAGE, HYDRAULIC PICKUP AND RETURN TUBES

Cub Cadet 2146 Specifications

General

Transmission Type	Hydrostatic
Drive	2WD
Front Tires	16 x 6.5-8
Engine Type	4-cycle OHV
Fuel Capacity	11.4 l
Wheelbase	119 cm
Weight	229 kg
