Cub Cadet 2146 Parts Manual

-24-
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 ME-110-3912 Head Assy, Cyl (Incl Ref 2, 4-17) 1
2 ME-110-3911 Head, Cylinder (Incl Ref 6-10) 1
3 ME-110-3591 Gasket, Cylinder Head 1
4 ME-110-3578 Valve, Intake 1
5 ME-110-3579 Valve, Exhaust 1
6 ME-167-0763-03 Spark Plug 1
7 ME-155-2378 Gasket, Exhaust 1
8 ME-110-3693 Guide, Intake Valve 1
9 ME-110-3694 Guide, Exhaust Valve 1
10 ME-110-3580 Ring, Valve Guide 2
11 ME-110-3587 Washer, Valve Spring 2
12 ME-110-0289 Seal, Intake Valve Stem 1
ME-509-0330 Seal, Exhaust Valve Stem 1
13 ME-110-3822 Spring, Valve 2
14 ME-110-3825 Retainer, Intake Valve Spring 1
15 ME-110-3826 Retainer, Exhaust Valve Spring 1
16 ME-110-3827 Lock, Intake Valve 2
17 ME-110-2752 Lock, Exhaust Valve 2
18 ME-800-3026 Screw, Hex Flange, M6 x 1 x 25 7
19 ME-110-3863-04 Cover, Valve 1
20 ME-110-3595 Bolt, Cyl. Head, M10 x 1.5 x 125 1
21 ME-518-0566 Clip, Retainer 2
22 ME-115-0473 Washer, Rocker Arm 2
23 ME-115-0424 Rod, Push 2
24 ME-115-0423 Tappet 2
25 ME-115-0426 Arm Assy, Rocker (Incl Ref 26-27) 2
26 ME-115-0428 Nut, Lash Adjusting, M7 x .75 2
27 ME-115-0427 Screw, Lash Adj, M7 x .75 x 18 2
28 ME-115-0429 Shaft, Rocker Arm 1
29 ME-516-2004 Pin, Dowel 1
30 ME-110-3892 Pin, Hollow Dowel 1
31 ME-123-2030 Connector, Breather Tube 1
32 ME-110-3594 Bolt, Cyl Head, M10 x 1.5 x 86 2
33 ME-110-3596 Bolt, Cyl Head, M8 x 1.25 x 50 1
34 ME-740-1008 Washer, Flat, M10 1
35 ME-123-2014 Breather 1
36 ME-110-3593 Bolt, Cyl Head, M10 x 1.5 x 66 2
37 ME-110-3830-01 Gasket, Valve Cover 1
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
CYLINDER HEAD

Cub Cadet 2146 Specifications

General

Transmission Type	Hydrostatic
Drive	2WD
Front Tires	16 x 6.5-8
Engine Type	4-cycle OHV
Fuel Capacity	11.4 l
Wheelbase	119 cm
Weight	229 kg
