Cub Cadet 2146 - SECTION V. MOWER DECK; SIDE-TO-SIDE LEVELING ADJUSTMENT

-31-
AIR CYLINDER HOUSING
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 ME-134-4991-02 Housing, Air Cylinder 1
2 ME-815-0829-04 Screw, Hx Hd TT, M8 x 1.25 x 16 4
3 ME-509-0324 O-Ring, Lower 1
4 ME-123-1970 Tube, Oil Fill 1
5 ME-509-0304 O-Ring, Upper 1
6 ME-123-1972-01 Indicator and Cap Ass’y. 1
7 ME-821-2033 Screw, Hx Flange Lock, M6 x 1 x 16 1
8 ME-403-3632-02 Bracket, Lift 1
