Cub Cadet 2146 Parts Manual

-32-
STARTER COMPONENTS
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1
ME-185-2659 Frame, Starter
1
2
ME-185-2661 Holder, Brush
1
3
ME-185-2662 Spring, Brush
4
4
ME-185-2664 Insulator
1
5
ME-185-2965 Hose, Drain
1
6
ME-185-263 Bearing, Oilless
1
7
ME-185-6383 Frame Assy, End (Incl. Ref #6)
1
8
ME-185-2660 Bolt, Through
2
9
ME-185-2367 Nut
1
10
ME-870-0465 Nut
1
11
ME-185-2381 Washer, Spring
1
12
ME-185-6381 Armature, Starter
1
13
ME-185-2658 Switch, Magnetic
1
14
ME-185-6382 Clutch
1
15
ME-185-6385 Nut, Pinion Stop
2
16
ME-185-6386 Ring, Snap
1
17
ME-185-2334 Nut
2
18
ME-185-6387 Washer, Plate
1
19
ME-185-2656 Lever, Starter Drive
1
20
ME-185-2706 Housing, Starter
1
21
ME-185-6384 Bearing, Oilless
1
ME-191-2107 Starter Assembly
1
REF.
NO.
PART
NUMBER DESCRIPTION QTY.

Cub Cadet 2146 Specifications

General

Transmission Type	Hydrostatic
Drive	2WD
Front Tires	16 x 6.5-8
Engine Type	4-cycle OHV
Fuel Capacity	11.4 l
Wheelbase	119 cm
Weight	229 kg
