Cub Cadet 2146 Parts Manual

-25-
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 ME-134-5005-02 Wheel Assy, Blower (Incl Ref 2 & Magnets) 1
2 ME-134-4773 Gear, Ring 1
3 ME-775-0061 Pin, Alignment 2
4 ME-191-1456-04 Stator 1
5 ME-191-1967 Clamp, Cord 1
6 ME-823-0003-02 Screw, Pan Head 2
7 ME-815-0638-01 Screw, Button Head Machine, M6 x 1 x 20 2
8 ME-526-0405 Washer, Flat, M18 1
9 ME-515-0295 Key 1
10 ME-870-2060 Nut, Flange, M18 x 1.5 1
11 ME-134-5006-02 Screen, Chaff 1
12 ME-718-1017 Screw, Hex Hd Cap, M6 x 1 x 10 1
BLOWER WHEEL

Cub Cadet 2146 Specifications

General

Transmission Type	Hydrostatic
Drive	2WD
Front Tires	16 x 6.5-8
Engine Type	4-cycle OHV
Fuel Capacity	11.4 l
Wheelbase	119 cm
Weight	229 kg
