Cub Cadet 2146 Parts Manual

-33-
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 703-2394 Bracket, RH Seat Pivot 1
2 703-2395 Seat, Base 1
3 703-2477 Bracket, LH Seat Pivot 1
4 710-0451 Bolt, Carriage, 5/16-18 x .75 6
5 710-1260 Screw, Hex Wsh Hd Tap, 5-16-18 x .75 4
6 712-3004A Nut, Hex Flange Lock, 5/16-18 8
7 720-0190 Knob, Seat Adjuster 1
8 731-3154 Slide, Seat 4
9 732-3080 Spring, Compression, 1.9 OD x 2.4 Lg 2
10 732-3098 Adjuster, Seat 1
11 738-0140 Bolt, Shoulder 2
12 738-0372 Spacer, Shoulder 4
13 757-3003 Seat, Medium Back 1
14 777D03267 Graphic, Seat Back 1
15 777I20310 Graphic, Seat Adjuster 1
16 777D01782 Graphic, Made in USA 1
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
SEAT AND SUPPORT

Cub Cadet 2146 Specifications

General

Transmission Type	Hydrostatic
Drive	2WD
Front Tires	16 x 6.5-8
Engine Type	4-cycle OHV
Fuel Capacity	11.4 l
Wheelbase	119 cm
Weight	229 kg
