Cub Cadet 2146 Parts Manual

-35-
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 603-0211 Bracket, Grille LH 1
2 603-0212 Bracket, Grille RH 1
3 603-0583 Bracket, Upper Hood 1
4 703-2396 Panel, RH Side 1
5 703-2397 Panel, LH Side 1
6 703-2398 Grille 1
7 703-2465 Link, Short Hood 2
8 703-2466A Link, Long Hood 2
9 703-2495 Screen, LH Panel 1
10 703-2496 Screen, RH Panel 1
12 710-0351 Screw, Truss Mach Tapp, #10 x .50 8
13 710-0599 Screw, Hex Wash Hd Tapp, 1/4 x .50 6
14 712-3027 Nut, Hex Flange Lock, 1/4-20 8
15 712-3087 Nut, Wing, 1/4-20 2
16 723-3059 Seal, Heat Baffle 1
17 726-0139 Nut, U-Type Speed, #10 2
19 625-0053 Headlight Assy (Includes Lamp and Socket) 1
725-0963 Lamp, 12V 2
725-1649 Socket, Lamp 2
20 777I20314 Graphic, Warning HOT 1
21 732-0334 Spring, Compression, .50 OD x .50 Lg 4
22 732-0855 Spring, Hood Latch 1
23 736-0175 Washer, Spring, .265 x .562 x .025 8
24 736-0400 Washer, Flat, .218 x .62 x .063 2
25 738-3141 Bolt, Shoulder, .31 Dia x .75 Lg 2
26 748-3055 Bushing, Tapered 4
27 759-3747 Hood, Series 2000 1
28 777D03263 Graphic, Hood RH 1
777D03264 Graphic, Hood LH 1
29 777D03291 Graphic, 2164 2
30 777X40079 Strip, Protective 2
GRILLE, HOOD AND SIDE PANELS

Cub Cadet 2146 Specifications

General

Transmission Type	Hydrostatic
Drive	2WD
Front Tires	16 x 6.5-8
Engine Type	4-cycle OHV
Fuel Capacity	11.4 l
Wheelbase	119 cm
Weight	229 kg
