Cub Cadet 2146 Parts Manual

-5-
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 603-0250 Segment Assy, 18T Steering 1
2 603-0064 Arm Assy, Lower Steering 1
3 603-0236A Housing Assy, (Incl.Ref #25, 29-30) 1
4 631-3209 Wheel, Steering, Soft Grip 1
5 710-0751 Screw, Hex Cap, 1/4 - 20 x .62, GR5 2
6 710-0376 Screw, Hex Hd Cap, 5/16 - 18 x 1.0 GR5 4
7 712-0237 Nut, Hex Center Lock, 5/16-18 5
8 712-3001 Nut, Hex Jam, 3/8-24 GR5 4
9 712-3012 Nut, Hex Slotted, 1/2-20 GR5 1
10 712-3027 Nut, Hex Flange Lock, 1/4-20 2
11 712-3054 Nut, Hex Lock, 3/8-24 GR5 4
12 714-0115 Pin, Cotter, 1/8 Dia x 1 1
13 714-3004 Pin, Cotter, 3/32 Dia x 1.25 1
14 717-3382 Pinion, Steering 1
15 722-3019 Gasket, Steering 1
16 723-0156 Joint, Ball, 3/8-24 4
17 731-3210 Insert, Steering Wheel Cover 1
18 736-0242 Washer, Bell, .340 x .88 x .06 Thk 1
19 736-0272 Washer, Flat, .510 x 1 x .06 Thk 1
20 796-0351 Washer, Flat, .760 x 1.5 x .03 Thk 1
21 736-0355 Washer, Flat, .56 x 1 x .04 Thk 1
22 736-0921 Washer, Lock, 1/2 1
23 736-3013 Washer, Flat, .531 x 1 x .027 Thk 2
24 736-3132 Wshr, Rubber Flat, .50x1.12x.125 Thk 1
25 737-3000 Fitting, Grease, 3/16 Drive Type 2
26 738-3105 Shaft, Steering 1
27 741-3025 Bearing, Flange 1
28 747-3171 Rod, Tie 2
29 748-0108 Bearing, Flange, .503 ID 1
30 748-3007A Bearing, Bronze Flange, .75 ID 2
STEERING

Cub Cadet 2146 Specifications

General

Transmission Type	Hydrostatic
Drive	2WD
Front Tires	16 x 6.5-8
Engine Type	4-cycle OHV
Fuel Capacity	11.4 l
Wheelbase	119 cm
Weight	229 kg
