2-13 Boot To Mower Deck Installation
Continued
Step 19: Insert (1) hair pin clip P#(K0099) as shown in
Figure 2-13u, to secure the boot rod.
Step 20: Examine the boot fit-up closely. Ensure that
there are no excessive gaps between the boot and the
mower deck. The aluminum boot should completely
cover the deck opening,
Insert Hair Pin Clip
As Shown
The Boot Should Fit Snug
Along These Edges
26
Figure 2-13u
Figure 2-13v
