17
E. Transmission Hi/Lo Range Shift Lever
The Hi/Lo range shift lever is located on the right
fender. The lever has two speed range settings and
a neutral position. The lever must be shifted into
either the high or low range prior to depressing the
forward/reverse pedal to drive the tractor.
• Push the lever forward to shift into the high
range.
• Push the lever rearward to shift into the low
range.
• Move the lever to the center position to shift
into the neutral position.
WARNING: Never attempt to shift the
range lever when the tractor is in
motion.
F. Cup Holder
The cup holder is located on the right fender.
G. Hand Holds
Hand holds are built into both the left and right hand
fender covers. The handles can be used to assist in
mounting and dismounting the tractor.
H. Amber Hazard Lights
The hazard lights are located on each side of the
ROPS bar. The lights illuminate in a flashing mode
when the hazard light switch is turned on. Always
use the hazard lights when it is necessary to warn
others that the tractor is being operated in the area.
J. Tail Lights
The tail lights illuminate when the ignition switch is
in the ON position and the headlight switch is
turned on.
K. Reverse Lights
The reverse lights illuminate when the tractor is
being operated in the reverse direction.
L. Storage Tray
The storage tray is located behind the seat. Use the
tray to carry small loose articles while operating the
tractor.
M. Foldable ROPS (Rollover Protective Structure)
ROPS is installed to prevent or reduce injuries to
the operator should the tractor accidentally over-
turn. The foldable feature allows the ROPS to be
lowered when operating in areas with low over-
head clearance. The protection provided by the
ROPS is minimized if the seat belt is not used and
eliminated when in the folded position.
N. Seat Belt
The seat belt, properly adjusted and used in
conjunction with the Rollover Protective Structure
(ROPS), can greatly reduce the risk of serious
injury or death to the operator if an accidental
tractor overturn occurs.
WARNING: DO NOT use the seat belt if
the ROPS is in the folded position, or
the structure has been removed from
the tractor.
O. Auxiliary Hydraulic Control Handle
The auxiliary hydraulic control handle is located on
the front of the right hand fender cover. Use this
handle to control the movement of attachments
connected to the auxiliary hydraulic system of the
tractor.
769-00802.book Seite 17 Mittwoch, 7. April 2004 5:38 17
