SECTION 1: CONTROLS AND FEATURES
FLOORBOARD AND DASH PANEL MOUNTED CONTROLS
Figure 1
B
C
D
E
F
G
H
J
K
L
M
A
A
B
C
D
E
F
G
H
J
K
L
M
Steering Wheel
PTO Switch
Throttle Handle
Ignition Switch
Brake Pedal
Forward/Reverse Pedal
Seat Adjustment Lever
Differential Lock Pedal
Parking Brake Lever
Hazard Light Switch
Headlight Switch
Instrument Panel
