5 Transmission
65
7. Remove the pinion shaft nut.
8. Remove the bearing holder.
9. Remove the gear for 2WD 4WD and sub
gearing.
Nut
GZ3W24-025
Bearingholder
Bearing
holder
Differentialcase
GZ3W24-026
Pinionshaft
4WDshaft
GZ3W24-027
Subgearingshaft
