Rear Axle and Brake 6
82
6.2 Differential Lock Pedal
7532(HST drive)
7530(Gear drive)
Arm
Differentiallockpedal
Rod
Plate
GZ3W25-018
Differentiallockpedal
PlateA
PlateB
"OFF"
"ON"
GZ3W25-002
www.mymowerparts.com
K&T Saw Shop 606-678-9623 or 606-561-4983
