6 Rear Axle and Brake
85
4. Remove the differential lock link and brake link.
5. Remove the axle case assembly.
Axlecover
Gear95T
Collar
Axleshaft
GZ3W25-007
Differentiallocklink
Brakelink
GZ3W25-008
Rearaxlecase
Differentialshaft
GZ3W25-009
