6 Rear Axle and Brake
94
6.6.1 Brake Pedal
Inspect the clearance between bush inside diameter for
the right brake pedal and brake shaft and replace the bush
exceeding the usable limit.
(Unit: mm {in})
Item Referential Value
Usable
Limit
Clearance bet. bush
and shaft
0.04 to 0.12
{0.0016 to 0.005}
0.5 {0.02}
Brakeshaft
Clearance
GS7W3-204
