Front Axle 7
99
12. Remove the deferential assembly.
7.2.2 Disassembly of Front Axle Assembly
Follow the following procedure to disassemble the front axle unit by unit.
1. Disassemble the front bracket and rear bracket.
1Bolt 2Bolt
3 Shim K 4 Nut
5 O-ring 6 Liner
7O-ring 8Bush
9 Front Bracket 10 O-ring
11 O-ring 12 Bush
13 Rear Bracket 14 Front Axle Assembly
Deferentialassembly
GZ3W26-012
Grease
Grease
Grease
Grease
Grease
9
8
7
5
4
3
10
14
13
11
12
6
1
2
GZ3W26-013
