Cub Cadet 7530

2 Installation and Removal of Engine Parts
12
4. Remove the air cleaner hose and air cleaner.
5. Remove the lower cover.
6. Remove the battery.
• Disconnect the positive terminal of the battery
cable
• Remove the fixing L-bolt from battery
7. Remove the muffler.
Aircleaner
Aircleanerhose
GZ3W21-004
Lowercover
GZ3W21-005
Battery
L-bolt
L-bolt
Positiveterminal
GZ3W21-006
muffler
GZ3W21-007
