4. Remove the return spring for brake pedal.
5. Remove the return spring for clutch pedal.
6. Remove the joint.
(HST Specification)
1) Remove the snap ring from the pin at joint end
and remove the joint.
7. Remove the shuttle damper. (HST Specification)
1) Remove the cottor pin from the pin of shuttle
damper bracket.
2) Remove the shuttle damper.
Returnspring
BrakepedalRH
BrakepedalLH
GZ3W22-020
Returnspring
Clutchpedal
GZ3W22-021
Joint
GZ3W22-022
Shuttledamper
GZ3W22-023
