HST 4
51
3. After adjustment, make sure the HST pedal is operable to both forward and backward sides.
Fix
Release
Reverse
Forward
N
Trunnionarm
Forwardstopper
Reversestopper
HSTpedal
Adjuster
Neutralarm
Grease
25to30{0.98to1.18}
21.5{0.84}
24{0.945}
Spring
92{3.62}
Bolt
Shaft
holder
Nut
Speedcontrolrod
(418{16.46})
Grease
Grease
mm{in}
