Lift Assembly
- Parts List for Figure 25
Ref.
No. Part No. Description Qty.
1 00011925 Hex Cap Screw, 3/8-16, 3.75 1
2 01007487 Rod End, Male 2
3 00012165 Nut, 5/16-18, Nylock 8
4 00012173 Nylock Insert Lock Nut, 3/8-16 2
5 00013432 Flat Washer, 5/8 7
6 00022560 Hex Nut, Flange Lock, 3/8-16 7
7 00035632 Jam Nut, 5/8-11 14
8 00060017 Flat Washer, .06, .776, 1.25 1
9 00060018 Cotter Pin, 3/16 x 1-1 2
10 01007526 Jam Nut, 5/8-18 2
11 00083192 Idler Washer 1
12 01001744 Eye Bolt, 5/8ID 2
13 01004917 Eye Bolt Mount Link, 5/8 ID 2
14 02000562 Deck Link 2
15 01001855 Ferule Lift 4
16 01001857 Lift Connector Rod 2
17 01001930 Hex Flange Bearing, 1.25 ID 4
18 01002586 Front Lift Link, Rod Mount 1
19 01003123 Spacer, .812 ID x .268 Lg. 3
20 01003318 Lift Compression Spring 2
21 01003534 Carriage Bolt, 3/8-16, 2.75 2
22 01003535 Shoulder Screw, 0.625 OD x .437 Lg. 4
23 01003536 Shoulder Screw, 0.625 OD x .830 Lg. 1
24 01003537 Cotter Pin, .148 x 3.00 1
25 01003993 Linch Pin, 3/16 Dia. 6
26 01003994 E Clip, 3/4 Dia. 4
27 01004003 Nylon Flat Washer, 5/8 6
28 01004080 Spacer, .39 ID x .63 OD x 1.442 2
29 01004118 Shoulder Screw, .50 OD x 0.27 1
30 01004968 Lift Pivot Assembly 1
31 01004971 Lift Handle Spring 1
32 01007804 Bearing Lift Brace Assembly, Right Hand 1
33 01007802 Bearing Lift Brace Assembly, Left Hand 1
34 01005569 Front Frame Strut Assembly 2
35 01006365 Lift Link Adjustment 1
36 01006823 Hose, 5/8 ID 13/16 OD, 8" LG 2
37 01007469 Lift Handle Assembly 1
38 01007561 Lift Handle Grip 1
39 01008207 Bellecrank Weldment Assembly 4
40 01007681 Deck Lift Shaft 2
41 01007962 Socket Head CapScrew, 5/16-18 x 2 8
42 01008627 Outer Lift Index Plate 1
43 01008628 Inner Lift Index Plate 1
44 01008652 Clevis Pin, .438 Dia. x 2.625 Lg. 1
45 01008671 Decal Height Indicator 1
46 01007527 Spacer, .630 ID x 1.06 OD x .440 4
47 01008453 Lift Link Rod 1
