Version 2 / 09.22
10
5.2.2 Connecting the brake hose to the brake lever
Procedure:
1. Turn the brake lever upwards and fix it lightly
2. Hold the hose end (brake lever side) pointing upwards
3. Cut off the seal (brake lever side) so that brake fluid can
run from the end of the hose into the brake lever when the
hose is removed
4. Do not operate the brake lever with the system open!
• Analog Online Tutorial:
• https://www.magura.com/en/compo
nents/techcenter/ Videos
Delivery condition:
• Sealed h
ose end
(brake body side)
• Sealed hose end brake lever side
