Cube Cargo Hybrid - Foliennummer 13

Version 2 / 09.22
13
14. Keep brake hose pressed into brake lever
15. Screw in connection bolt by hand, tighten with 4Nm
4Nm
16. Slide rubber cover over the connection bolt once more
17. Check brake for safe operation!
18. Turn brake lever back into driving position and tighten
