Cube Cargo Hybrid - Foliennummer 32

Version 2 / 09.22
32
1. Screw in 2x ISO 4762 M8x40 screw with washer and nut on left and right hand side,
u
ntil stand is positioned centrally.
2. Tighten
the screws only slightly until the stand is seated without play, do not tighten completely
3. Attach tension springs for stand return
4. Lock the nuts against the stand
screw
ISO 4762 M8x40
nut
ISO 4032 M8
washer
ISO 7092 M8x1,6
screw
ISO 4762 M8x40
nut
ISO 4032 M8
washer
ISO 7092 M8x1,6
2x tension spring
