Version 2 / 09.22
11
8. Leaving a 10mm projection, press the brake hose into the
clamp block.
Fix it using 2nd clamp block and water pump pliers
7. Hold the brake body end of the brake hose with the sealed
opening pointing upwards and cut it off just behind the
sealing clamp
5. Loosen the connection screw (2) with an 8mm open-end
wrench
6. Remove and dispose of the hose end
