Cube Cargo Hybrid - Foliennummer 33

Version 2 / 09.22
33
6.3 Assembly instructions for dropout adapter
• ISO4762 M6x16, strength class 10.9 (4x)
• Apply liquid thread lock to screw thread
• Tightening torque 15 Nm
6.4 Assembly instruction for belt opening
• ISO4762 M6x16 (2x)
• Tightening torque 10 Nm
