Cube MTB - Torques of Screw Connections; 4 Assembly and Function; Categories

16 |
MTB/ ROAD BIKE/ TREKKING
MTB/ ROAD BIKE/ TREKKING
You will nd the category and model further
information of your bicycle in delivery cer-
ticate, last page of this maunal.
During the purchase, please check if eve-
rything has been lled out completely and
correctly with the help of your bicycle dealer.
4 Assembly and function
4.1 Categories
We divide our bicycles into the following
categories. Within these categories,
there are dierent series.
•
Mountain bike
- Fully (= front and rear wheel suspension,
see also chapter 4.2.1)
- Hardtail (= front wheel suspension, no rear
wheel suspension, see also chapter 4.2.2)
3.3 Torques of screw connections
Part
Manufac-
turer
Model/Type Connection
Type of
Connection
Torque (Nm)
seat post
Syntace P6
clamping
saddle
2 screws 6-8
Easton EA30 2 screws 8
RFR
1 screw
+ 1 put ting
wheel
8-10
Scape 2 screws 8-10
FSA SL-280 1 screw 16,5
Triathlon aluminium 2 screws 8-10
Ritchey TT Stubby 1 screw 12
seat post Triathlon carbon
clamping
saddle sledge
2 screws 5-6
seat post clamp / frame
aluminium
clamping seat
post
1 screw 5-8
titanium 1 screw 5-8
carbon frame 1 screw 5-6
carbon seat
post
1 screw
5-6
please also refer to
seat post manual
Tria aluminium 2 screws 4-5
Tria carbon
2 screws
specication
1 screw
2-3
2-3
bottlecage / frame any any
screw joint
bottle cage
2 screws 3
cable guide clamp any any each screw 3
rear carrier any any
screw joint
rear carrier
each screw 6
•
Cross bike
•
Cyclocross
•
Racing bike
•
Fitnessbikes/ Urban
•
Trekking bike
•
Pedelec
