Cube MTB User Manual

| 3
MTB/ ROAD BIKE/ TREKKING
In the following image you will nd a bike which shows all necessary parts, listed in the manual.
We choosed an example of the wide range of bikes on the market.
01 chain rings
02 crankset
03 pedals
04 front derailleur
05 chain
06 rear derailleur
07 sprocket cluster
08 shifter
09 brake levers
10 brakes
10 a brake disc
10 b brake caliper
10 c brakebooster
11 quick-release axles
12 hubs
13 seat post
14 seat clamp
15 frame
15 a chain stay
15 b seat stay
15 c linkage
16 fork
17 rear shock
18 wheels
19 bar
20 stem
21 head set
22 rear carrier
23 light system
24 mud guard
