CDR-3250/80 TECHNICAL MANUAL
Table 1-1 CDR-3250/80 Specifications-Cont.
Item Specification
1-6 Issue 2.2
ENVIRONMENTAL DATA
Temperature Range 0 to +50°C Operating, -40 to +85°C Storage.
OPTIONS
RCU-3100 Remote Controller (Serial bus option must be installed). Controls up to 10 receivers, expandable to
100 receivers. Line audio handling up to 10 receivers.
High-performance reference
oscillator
OCXO, 0.1 ppm of tuned frequency
Serial Data Bus RS-232 or RS-422
Parallel Data Bus IEEE-488
Rack-Mount Slides Slides for CDR-3250 for installation into 19-inch rack.
Dual Rack Mount Kit Hardware and slides to fasten two CDR-3280 receivers together for installation in
standard 19-inch rack
DC Power 20-32 VDC. 3A maximum
