CDR-3250/80 TECHNICAL MANUAL
Issue 2.2 1-7/(1-8 blank)
Table 1-2 Items Furnished.
Part No. Nomenclature Furn./Optl.
260001-XX
1
CDR-3250 or CDR-3280 VLF - HF Digital Receiver Furn.
696-012 AC power cord Furn.
2600-1021-1 Technical manual Furn.
2600-1009-1 Rack Mount Kit, Dual (for CDR-3280 only) Optl. Not furnished
222-088 Mounting slides for rack mount (for CDR-3250 only) Optl. Not furnished
222-026 Mounting brackets for slides Optl. Not furnished
324-009/324-010 Audio Connector/Hood (cable end) Optl. Not furnished
324-070/324-010 Digital Data Connector/Hood (cable end) Optl. Not furnished
1
XX indicates model number and factory installed options. Refer to identification plate on equipment.
Table 1-3 Recommended Tools and Test Equipment (Or Equivalent).
Part No. Nomenclature Manufacturer
- Screwdriver, Phillips 6 inch, No. 1 Any
- Screwdriver, Phillips 6 inch, No. 2 Any
- Driver, nut, 1/4 inch Any
- Wrench, open end, 3/16 inch Any
- Wrench, Allen, .050 inch Any
- Wrench, Allen, 1/16 inch Any
- Wrench, Allen, 7/64 inch Any
HP8642B RF signal generator Hewlett Packard
465B Oscilloscope Tektronix
8050A Digital multimeter (true RMS) Fluke
HP5381A Frequency counter
1
Hewlett Packard
HP8568B Spectrum analyzer
1
Hewlett Packard
1
Optional
