CDR-3250/80 TECHNICAL MANUAL
Issue 2.2 3-11
MODE Soft Key Menu.
LSB USB CW AM CANCEL
MTR
MNU
NEXT
Press the desired receive mode, or press the NEXT key and the following menu appears.
MODE - NEXT Soft Key Menu.
ISB FM FSK CANCEL
MTR
MNU
NEXT
Press the desired receive mode, or press the NEXT key to show the previous menu.
NOTE
When ISB reception mode is selected, a small U or L will be shown after the ISB in
the display. This indicates which sideband's audio (upper or lower) is being
monitored (sent to the PHONES jack and shown on the display). When in ISB, the
upper sideband audio is always applied to the NORM audio line and the lower
sideband audio is always applied to the ALTN audio line on the rear panel connector.
Separate AGC and squelch settings are available for each sideband.
The ISB monitor mode may be changed when the meter display is shown. Press the MTR/MNU key as shown below to select
the meters display.
Primary Soft Key Menu.
FREQ MODE BW SQELCH GAIN
MTR
MNU
NEXT
The following display appears.
ISB Monitor Soft Key Menu.
(RF Meter Display) (AF Meter Display)
SELECT
MTR
MNU
NEXT
Press SELECT to toggle the ISB monitor mode (Upper or Lower).
