CDR-3250/80 TECHNICAL MANUAL
Issue 2.1 3-13
BW - NEXT - TABLE Soft Key Menu.
ASSIGN DEFLT ENTER CANCEL
MTR
MNU
NEXT
When the TABLE key is pressed BW: XXX is shown in the display. Rotate the main adjustment knob to select and change one
of fifty-one bandwidths from 100 Hz to 16.0 kHz (or 6.0 kHz) depending on receive mode. After the desired bandwidth is
displayed, press the ENTER key to enter the receiver bandwidth and exit the Bandwidth menu. If the CANCEL key is pressed
instead of the ENTER key, the receiver reverts back to the original bandwidth.
3-7.2.3.1 Assigning Bandwidths to Soft Key Labels.
The bandwidth soft key labels may be assigned different values from the
bandwidth table using the ASSIGN function. To assign the bandwidths select the BW - NEXT - TABLE soft key menu as
shown below. Rotate the main adjustment knob to select the desired bandwidth in the display.
BW - NEXT - TABLE Soft Key Menu.
ASSIGN DEFLT ENTER CANCEL
MTR
MNU
NEXT
Press the ASSIGN key to select the desired bandwidth from the table to the soft key menu. The following menu is displayed.
BW - NEXT - TABLE - ASSIGN Soft Key Menu.
300* 1.0* 2.8* 6.0* RETURN
MTR
MNU
NEXT
Press the desired soft key to reassign to a bandwidth, or press the NEXT key to display the additional bandwidth menu.
BW - NEXT - TABLE - ASSIGN - NEXT Soft Key Menu.
600* 2.0* 8.0* RETURN
MTR
MNU
NEXT
Press the desired soft key to assign to a bandwidth. The following menu is displayed.
BW - NEXT - TABLE Soft Key Menu.
ASSIGN DEFLT ENTER CANCEL
MTR
MNU
NEXT
Press the CANCEL key or assign additional bandwidths if desired.
