CDR-3250/80 TECHNICAL MANUAL
3-16 Issue 2.2
GAIN Soft Key Menu.
0.02* 0.20* 3.00* MGC CANCEL
MTR
MNU
NEXT
Press the desired AGC decay setting, or press the NEXT key for more settings.
GAIN - NEXT Soft Key Menu.
0.10* 0.60* 1.00* TABLE CANCEL
MTR
MNU
NEXT
Press the desired AGC decay setting, or press the TABLE key for more settings.
GAIN - NEXT - TABLE Soft Key Menu.
ASSIGN DEFLT ENTER CANCEL
MTR
MNU
NEXT
Select the AGC decay value using the main adjustment knob only. Range = 0.00 sec. to 4.00 sec. Press the ENTER key when
done.
GAIN Soft Key Menu.
0.02* 0.20* 3.00* MGC CANCEL
MTR
MNU
NEXT
When the GAIN soft key menu is displayed, press the MGC key to select manual gain control. The following menu appears.
GAIN - MGC Soft Key Menu.
BKSP ENTER CANCEL
MTR
MNU
NEXT
Select the manual gain value using the keypad or main adjustment knob. Press the ENTER key when the desired manual gain
is displayed. Range = -000.0 dB to -127.5 dB in .5 dB steps.
*Operator assignable value. May be different than shown.
