RO Module Tubing
For 3-D tube fitting diagrams, see the parts section starting on page 28.
MODEL E2-2 Plus MODEL E2-3 Plus
MODEL E2-4 Plus
CENTER PORT
OF END CAPS.
CENTER PORT
OF END CAPS.
CENTER PORT
OF END CAPS.
CENTER PORT
OF END CAPS.
CENTER PORT
OF END CAPS.
CENTER PORT
OF END CAPS.
OFF-CENTER PORT
OF END CAPS
OFF-CENTER PORT
OF END CAPS
OFF-CENTER PORT
OF END CAPS
Figure 3. E2 Plus Module Tubing, two to four membranes.
